|$0
AXLE ASSEMBLY, FRONT(SEE FIG. F4400-01A0)
SN: A60001-UP-UP
1шт.
|$1
AXLE ASSEMBLY, REAR(SEE FIG. F4500-01A0)
SN: A60001-UP-UP
1шт.
|$2
425-33-11006
BRAKE ASSEMBLY
SN: A60001-UP-UP
4шт.
1
425-33-11151
CYLINDER
SN: A60001-UP-UP
1шт.
2
581-32-12140
PLUG
SN: A60001-UP-UP
1шт.
3
566-32-11430
BLEEDER
SN: A60001-UP-UP
1шт.
4
566-32-11620
CAP
SN: A60001-UP-UP
1шт.
5
07043-50211
PLUG
SN: A60001-UP-UP
1шт.
6
07040-11409
PLUG
SN: A60001-UP-UP
2шт.
7
07002-31423
O-RING - PLUG
SN: A60001-UP-UP
2шт.
8
07040-12012
PLUG - SHIPPING ONLY
SN: A60001-UP-UP
2шт.
9
07002-02034
O-RING, PLUG - SHIPPING ONLY
SN: A60001-UP-UP
2шт.
10
421-33-11440
SEAL - PISTON
SN: A60001-UP-UP
1шт.
11
425-33-11261
PISTON
SN: A60001-UP-UP
1шт.
12
425-33-11410
SEAL
SN: A60001-UP-UP
1шт.
13
425-33-11361
GUIDE
SN: A60001-UP-UP
6шт.
14
421-33-11620
SPRING
SN: A60001-UP-UP
6шт.
15
04020-00514
PIN, DOWEL
SN: A60001-UP-UP
6шт.
16
07000-F5315
O-RING - CYLINDER
SN: A60001-UP-UP
1шт.
17
07000-F3030
O-RING - GUIDE
SN: A60001-UP-UP
8шт.
18
07000-F5490
O-RING - CYLINDER
SN: A60001-UP-UP
1шт.
19
01010-31450
BOLT
SN: A60001-UP-UP
20шт.
20
01643-31445
WASHER
SN: A60001-UP-UP
20шт.
21
425-33-11322
RETAINER
SN: A60001-UP-UP
1шт.
22
07000-F5350
O-RING - RETAINER
SN: A60001-UP-UP
1шт.
23
04020-00820
PIN
SN: A60001-UP-UP
2шт.
|$26
425-33-00111
FLOATING SEAL ASSEMBLY
SN: A60001-UP-UP
1шт.
24
421-33-00040
SEAL RING ASSEMBLY
SN: A60001-UP-UP
1шт.
25
425-33-00120
O-RING ASSEMBLY
SN: A60001-UP-UP
1шт.
26
425-33-11221
HUB
SN: A60001-UP-UP
1шт.
27
566-09-31160
SEAL - HUB
SN: A60001-UP-UP
1шт.
28
07000-F5490
O-RING - HUB
SN: A60001-UP-UP
1шт.
29
07000-F2016
O-RING - GEAR
SN: A60001-UP-UP
2шт.
30
425-33-11212
GEAR
SN: A60001-UP-UP
1шт.
31
01010-31440
BOLT
SN: A60001-UP-UP
16шт.
32
01643-31445
WASHER
SN: A60001-UP-UP
16шт.
33
566-33-41230
PLATE
SN: A60001-UP-UP
6шт.
34
425-33-11510
DISC
SN: A60001-UP-UP
5шт.
35
BOLT - FRONT AXLE (SEE FIG. F4400-01A0)
SN: A60001-UP-UP
22шт.
|$40
OR
-1шт.
35
BOLT - REAR AXLE (SEE FIG. F4500-01A0)
SN: A60001-UP-UP
22шт.
|$43
425-33-05020
KIT, SERVICE - WHEEL BRAKE
SN: A60001-UP-UP
1шт.
|$44
-1шт.
|$45
F1 - INCLUDED IN WHEEL BRAKE SERVICE KIT.
-1шт.
|$46
-1шт.
