|$0
AXLE ASSEMBLY - FRONT(SEE FIG. F4400-01A0)
SN: A60001-UP-UP
1шт.
|$1
AXLE ASSEMBLY - REAR(SEE FIG. F4500-01A0)
SN: A60001-UP-UP
1шт.
|$2
425-22-12004
DRIVE ASSEMBLY - FINAL
SN: A60001-UP-UP
2шт.
1
425-22-12440
SHAFT, L.H. FRONT - R.H. REAR
SN: A60001-UP-UP
1шт.
|$4
425-22-12410
SHAFT, R.H. FRONT - L.H. REAR
SN: A60001-UP-UP
1шт.
2
425-22-12711
HUB
SN: A60001-UP-UP
2шт.
3
421-22-12840
BEARING
SN: A60001-UP-UP
2шт.
4
425-22-12130
RETAINER
SN: A60001-UP-UP
2шт.
5
421-22-12870
BEARING
SN: A60001-UP-UP
2шт.
6
421-22-12310
HUB
SN: A60001-UP-UP
2шт.
7
425-22-12210
RETAINER
SN: A60001-UP-UP
2шт.
8
425-22-00050
SHIM KIT
SN: A60001-UP-UP
2шт.
|$12
NSS
SHIM - 0.008 IN. (0.20 MM)
SN: A60001-UP-UP
4шт.
|$13
NSS
SHIM - 0.012 IN. (0.30 MM)
SN: A60001-UP-UP
4шт.
|$14
NSS
SHIM - 0.039 IN. (1.00 MM)
SN: A60001-UP-UP
2шт.
9
01010-31660
BOLT
SN: A60001-UP-UP
16шт.
10
425-22-12540
GEAR
SN: A60001-UP-UP
2шт.
11
566-22-12561
PLATE
SN: A60001-UP-UP
12шт.
12
01010-30820
BOLT
SN: A60001-UP-UP
24шт.
13
01643-30823
WASHER
SN: A60001-UP-UP
24шт.
14
425-22-12430
SPACER
SN: A60001-UP-UP
2шт.
15
425-22-12421
GEAR
SN: A60001-UP-UP
2шт.
16
04064-06525
RING, SNAP
SN: A60001-UP-UP
2шт.
|$23
425-22-12101
CARRIER ASSEMBLY - FINAL DRIVE
SN: A60001-UP-UP
2шт.
17
425-22-12612
CARRIER
SN: A60001-UP-UP
1шт.
18
425-22-12580
GEAR
SN: A60001-UP-UP
3шт.
19
425-22-12570
BEARING
SN: A60001-UP-UP
6шт.
20
425-22-12910
RING, RETAINING
SN: A60001-UP-UP
3шт.
21
425-22-12510
SHAFT
SN: A60001-UP-UP
3шт.
22
04260-01587
BALL
SN: A60001-UP-UP
3шт.
23
07000-05435
O-RING - CARRIER
SN: A60001-UP-UP
2шт.
24
01252-31025
BOLT
SN: A60001-UP-UP
6шт.
25
425-22-12624
COVER
SN: A60001-UP-UP
2шт.
26
286-22-12630
BUTTON
SN: A60001-UP-UP
2шт.
27
07041-13612
PLUG
SN: A60001-UP-UP
2шт.
28
07002-03634
O-RING - PLUG
SN: A60001-UP-UP
2шт.
29
07044-12412
PLUG
SN: A60001-UP-UP
2шт.
30
07002-02434
O-RING - PLUG
SN: A60001-UP-UP
2шт.
31
07000-05340
O-RING - COVER
SN: A60001-UP-UP
2шт.
32
07000-03028
O-RING - COVER
SN: A60001-UP-UP
2шт.
33
01010-81230
BOLT
SN: A60001-UP-UP
12шт.
34
01643-31232
WASHER
SN: A60001-UP-UP
12шт.
35
01144-62070
STUD - WHEEL MOUNTING
SN: A60001-UP-UP
62шт.
36
423-22-12790
NUT, LUG - WHEEL MOUNTING
SN: A60001-UP-UP
62шт.
37
01643-32060
WASHER
SN: A60001-UP-UP
62шт.
|$45
425-22-05020
KIT, SERVICE - FRONT AND REAR AXLESFINAL DRIVE
SN: A60001-UP-UP
4шт.
|$46
-1шт.
|$47
F1 - INCLUDED IN FINAL DRIVE SERVICE KIT.
-1шт.
|$48
-1шт.
