1
COMPRESSOR ASSEMBLY(SEE FIG. K0718-01A0)
SN: A60001-UP-UP
1шт.
2
01010-80820
BOLT - COMPRESSOR MOUNTING
SN: A60001-UP-UP
4шт.
3
01643-30823
WASHER
SN: A60001-UP-UP
4шт.
4
418-963-1140
BRACKET - COMPRESSOR MOUNTING
SN: A60001-UP-UP
1шт.
5
01011-51275
BOLT - COMPRESSOR MOUNTING
SN: A60001-UP-UP
1шт.
6
01643-31232
WASHER
SN: A60001-UP-UP
2шт.
7
01580-11210
NUT
SN: A60001-UP-UP
1шт.
8
419-07-11760
COLLAR
SN: A60001-UP-UP
2шт.
9
01010-81225
BOLT - BELT TENSION
SN: A60001-UP-UP
1шт.
10
01643-31232
WASHER
SN: A60001-UP-UP
1шт.
11
425-963-A111
BRACKET - TO ENGINE BLOCK
SN: A60001-UP-UP
1шт.
12
24 860 R1
BOLT - 1/2 NC X 1 IN. - BRACKET TOENGINE BLOCK
SN: A60001-UP-UP
2шт.
13
01640-21323
WASHER
SN: A60001-UP-UP
2шт.
14
01010-31235
BOLT - BRACKET TO BRACKET
SN: A60001-UP-UP
1шт.
15
01643-31232
WASHER
SN: A60001-UP-UP
1шт.
16
425-963-A120
BRACKET - TO ENGINE BLOCK
SN: A60001-UP-UP
1шт.
|$17
OR
-1шт.
16
425-963-AG10
BRACKET - TO ENGINE BLOCK
SN: A60001-UP-UP
1шт.
17
24 849 R1
BOLT - 7/16 NC X 1 IN. - BRACKET TO ENGINE BLOCK
SN: A60001-UP-UP
1шт.
18
01640-21123
WASHER
SN: A60001-UP-UP
1шт.
19
04120-43098
V-BELT
SN: A60001-UP-UP
1шт.
N/I
425-963-A460
WIRE, ADAPTER
SN: A60001-UP-UP
1шт.
