1
07323-B0300
ELBOW
SN: A60001-UP-UP
2шт.
2
425-35-11471
ELBOW
SN: A60001-UP-UP
1шт.
3
07324-90300
TEE
SN: A60001-UP-UP
1шт.
4
421-09-12580
ELBOW
SN: A60001-UP-UP
2шт.
5
421-35-13122
TUBE
SN: A60001-UP-UP
1шт.
6
421-35-13132
TUBE
SN: A60001-UP-UP
1шт.
7
421-09-12580
ELBOW
SN: A60001-UP-UP
2шт.
8
281-34-12300
VALVE, CHECK - AT R.H. TREADLE VALVE
SN: A60001-UP-UP
1шт.
9
281-34-12310
SHUTTLE
SN: A60001-UP-UP
1шт.
10
281-34-12320
GASKET
SN: A60001-UP-UP
1шт.
11
07043-00312
PLUG
SN: A60001-UP-UP
1шт.
12
425-35-11471
ELBOW
SN: A60001-UP-UP
1шт.
13
421-35-14350
VALVE, CHECK - AT L.H. TREADLE VALVE
SN: A60001-UP-UP
1шт.
14
281-34-12310
SHUTTLE
SN: A60001-UP-UP
1шт.
15
281-34-12320
GASKET
SN: A60001-UP-UP
1шт.
16
07325-30300
NIPPLE
SN: A60001-UP-UP
1шт.
17
07323-B0300
ELBOW
SN: A60001-UP-UP
2шт.
18
421-09-12550
ELBOW
SN: A60001-UP-UP
1шт.
19
421-09-12730
CONNECTOR
SN: A60001-UP-UP
1шт.
20
425-35-13231
TUBE - TO R.H. MOUNTED CHECK VALVE
SN: A60001-UP-UP
1шт.
21
425-35-13221
TUBE - TO L.H. MOUNTED CHECK VALVE
SN: A60001-UP-UP
1шт.
22
425-06-15111
SWITCH - TRANSMISSION CUT-OFF
SN: A60001-UP-UP
1шт.
23
421-09-12720
ADAPTER
SN: A60001-UP-UP
1шт.
24
421-06-11570
SWITCH - STOP LAMP
SN: A60001-UP-UP
1шт.
25
07326-30302
ADAPTER
SN: A60001-UP-UP
1шт.
26
424-35-11910
CLAMP
SN: A60001-UP-UP
1шт.
27
424-35-11920
CLAMP
SN: A60001-UP-UP
1шт.
28
01435-01016
BOLT
SN: A60001-UP-UP
1шт.
29
04434-51510
CLIP
SN: A60001-UP-UP
2шт.
30
01435-01020
BOLT
SN: A60001-UP-UP
2шт.
31
VALVE ASSEMBLY - TREADLE(SEE FIG. K4462-01A0)
SN: A60001-UP-UP
2шт.
32
HOSE - TO BRAKE CHAMBERS(SEE FIG. K4460-03A0)
SN: A60001-UP-UP
2шт.
|$32
281-34-05220
KIT, SERVICE - CHECK VALVE
SN: A60001-UP-UP
2шт.
|$33
-1шт.
|$34
F1 - INCLUDED IN CHECK VALVE SERVICE KIT.
-1шт.
|$35
-1шт.
