/ / / / / / FIG. E-A ЛЕВ. TURN SIGNAL И ПАРКОВОЧН. LIGHT
Запчасти Komatsu WA500-1LC FIG. E-A ЛЕВ. TURN SIGNAL И ПАРКОВОЧН. LIGHT ЭЛЕКТРИКА
8
7
3
1
6
5
6
2
4
3
6
5
6
4
|$0
421-06-13301
LIGHT ASSEMBLY - TURN SIGNAL AND PARKING
SN: A60001-UP-UP
1шт.
1
22W-06-12310
LENS - LIGHT
SN: A60001-UP-UP
1шт.
2
421-06-13310
BULB - 10/4 W
SN: A60001-UP-UP
1шт.
3
08105-12420
BULB - 25 W
SN: A60001-UP-UP
2шт.
4
01220-50450
SCREW - MOUNTING
SN: A60001-UP-UP
2шт.
5
01220-50416
SCREW - MOUNTING
SN: A60001-UP-UP
2шт.
6
01641-40405
WASHER - MOUNTING
SN: A60001-UP-UP
4шт.
7
NSS
HOUSING
SN: A60001-UP-UP
1шт.
8
NSS
SEAL
SN: A60001-UP-UP
1шт.
N/I
08021-00400
CONNECTOR
SN: A60001-UP-UP
6шт.
N/I
08022-04001
CONNECTOR
SN: A60001-UP-UP
2шт.
