1
425-03-A2130
HOSE, THERMOSTAT TO RADIATOR
1шт.
2
07281-00809
CLAMP, HOSE
3шт.
3
425-03-A2520
TUBE, THERMOSTAT TO RADIATOR
1шт.
4
425-03-A2120
HOSE, THERMOSTAT TO RADIATOR
1шт.
5
07281-00809
CLAMP, HOSE
4шт.
6
425-03-12140
HOSE, RADIATOR TO WATER PUMP (LOWER LINE)
1шт.
7
07281-01029
CLAMP, HOSE
4шт.
8
425-03-A2530
TUBE, RADIATOR TO WATER PUMP (LOWER LINE)
1шт.
9
07042-70415
PLUG
1шт.
10
425-03-A2250
HOSE, RADIATOR TO WATER PUMP (LOWER LINE)
1шт.
11
07281-00909
CLAMP, HOSE
3шт.
12
286-03-11440
NIPPLE
1шт.
13
09483-06090
HOSE, WATER PUMP TO RADIATOR (UPPER LINE)
1шт.
14
07281-00419
CLAMP, HOSE
2шт.
15
113-899-7950
CLIP, HOSE
2шт.
16
01010-51020
BOLT, CLIP
2шт.
17
01643-31032
WASHER
2шт.
18
42A-16-11210
BRACKET, CLIP HOSE TO CORROSION RESISTER
1шт.
19
140 483 H
BOLT, 3/8NC X 1 1/4 - BRACKET
1шт.
20
09483-00311
HOSE, THERMOSTAT TO RADIATOR
1шт.
21
07281-00197
CLAMP, HOSE
2шт.
22
424-06-12740
CLIP, HOSE
1шт.
23
01010-51020
BOLT, CLIP
1шт.
24
01643-31032
WASHER
1шт.
25
293 344 C1
ELBOW, AT THERMOSTAT HOUSING
1шт.
26
07730-30004
VALVE, RADIATOR DRAIN
1шт.
27
07260-21435
HOSE, RADIATOR DRAIN
1шт.
28
07281-00259
CLAMP, DRAIN HOSE
1шт.
29
7861-91-4540
SENSOR, RADIATOR WATER LEVEL
1шт.
30
07002-23634
O-RING, SENSOR
1шт.
