1
DAMPER ASS'Y,(SEE FIG. K0710-03A0)
SN: A71001-UP
-1шт.
2
DUCT ASS'Y,(SEE FIG. K0710-04A0)
SN: A71001-UP
-1шт.
3
425-07-21160
RELAY
SN: A71001-UP
8шт.
4
421-07-21190
CAP
SN: A71001-UP
2шт.
5
421-07-21280
HOSE,DRAIN
SN: A71001-UP
2шт.
6
20Y-979-3120
TANK
SN: A71001-UP
1шт.
7
01435-00620
BOLT
SN: A71001-UP
2шт.
8
AIR CONDITIONER U.,(SEE FIG. K0710-05A0)
SN: A71001-UP
-1шт.
9
425-07-21121
CONTROLLER,AIR CONDITIONER
SN: A71001-UP
1шт.
10
AIR COMPRESSOR A.,(SEE FIG. K0710-06A0)
SN: A71001-UP
-1шт.
11
CONDENSER ASS'Y,(SEE FIG. K0710-08A0)
SN: A71001-UP
-1шт.
12
FILTER BOX ASS'Y,(SEE FIG. K0710-02A0)
SN: A71001-UP
-1шт.
13
DUCT,(SEE FIG. K0712-01A0)
SN: A71001-UP
-1шт.
14
WIRING HARNESS,(SEE FIG. K0711-02A0)
SN: A71001-UP
-1шт.
