Запчасти Komatsu WA500-7 H-A ГИДР. НАСОС. ПОГРУЗ. НАСОС (END КРЫШКА) (/8) ГИДРАВЛИКА

|$15

PUMP ASSEMBLY (SEE FIG. H0210-01A0 )

0

-1шт.

|$16

.PUMP SUBASSEMBLY (SEE FIG. H0210-01A0 )

1

-1шт.

|$2

708-1H-04610

CAP ASSEMBLY, END

1шт.

1

NSS

CAP, END

1шт.

2

NSS

PLUG

19шт.

3

708-2H-12430

BEARING

1шт.

4

07000-A5190

O-RING

1шт.

5

07000-B2012

O-RING

5шт.

6

04020-01434

PIN, DOWEL

1шт.

7

01010-61860

BOLT

5шт.

8

01643-31845

WASHER

5шт.

9

708-1L-29340

ORIFICE

1шт.

10

708-2L-25480

FILTER

2шт.

11

708-8E-16150

PLUG

1шт.

12

07002-61023

O-RING

1шт.

|$17

15

-1шт.

|$18

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

16

-1шт.
