Запчасти Komatsu WA500-7 C-A РАДИАТОР ВЕНТИЛЯТОР ОХЛАЖДЕНИЯ МОТОР (/) СИСТЕМА ОХЛАЖДЕНИЯ

|$6

MOTOR ASSEMBLY (SEE FIG. C0110-04A0)

0

-1шт.

|$1

708-7T-01430

COVER SUBASSEMBLY

1шт.

1

708-7T-02340

VALVE, RELIEF

1шт.

2

07000-F2016

O-RING

1шт.

3

07001-02016

RING, BACK-UP

1шт.

4

07002-22434

O-RING

1шт.

|$7

6

-1шт.

|$8

F1 - THIS PART IS SUPPLIED AS PART OF THE ASSEMBLY. HOWEVER, IT IS AVAILABLE AS AN INDIVIDUAL PART TO AUTHORIZED DISTRIBUTORS ONLY.

7

-1шт.
