|$0
TRANSMISSION ASSEMBLY (SEE PG 02-012)
-29шт.
1
426-15-13320
SHAFT
1шт.
2
425-15-13260
COLLAR
1шт.
3
426-15-13242
GEAR
1шт.
4
426-15-13170
CAGE
1шт.
5
07000-05220
O-RING, CAGE
1шт.
6
01010-51230
BOLT, MOUNT CAGE
4шт.
7
01643-31232
WASHER
4шт.
8
426-15-13350
BEARING
1шт.
9
07012-10125
SEAL, OIL - FRONT COUPLING CAGE
1шт.
10
426-15-13160
CAGE, FRONT COUPLING
1шт.
11
07000-05180
O-RING, FRONT COUPLING CAGE
1шт.
12
426-15-05040
SHIM ASSEMBLY, FRONT COUPLING
1шт.
|$13
NSS
SHIM, 0.15mm
4шт.
|$14
NSS
SHIM, 0.2mm
4шт.
|$15
NSS
SHIM, 0.3mm
4шт.
13
01010-51230
BOLT, MOUNT CAGE
4шт.
14
01643-31232
WASHER
4шт.
15
426-15-13251
COUPLING, FRONT
1шт.
16
426-15-13260
HOLDER, FRONT COUPLING
1шт.
17
07000-05075
O-RING, HOLDER - FRONT COUPLING
1шт.
18
01051-52420
BOLT, MOUNT FRONT COUPLING
1шт.
19
01643-32460
WASHER
1шт.
20
144-13-11161
BEARING
1шт.
21
04064-08530
RING, SNAP
1шт.
22
07012-10105
SEAL, OIL - REAR COUPLING
1шт.
23
426-15-13180
CAGE, REAR COUPLING
1шт.
24
07000-05155
O-RING, REAR COUPLING CAGE
1шт.
25
01010-51235
BOLT, MOUNT CAGE
4шт.
26
01643-31232
WASHER
4шт.
27
426-15-13290
COUPLING, REAR
1шт.
N/I
SERVICE KIT, TRANSMISSION (SEE PG 02-058)
-29шт.
|$34
-1шт.
|$33
F2 - INCLUDED IN SERVICE KIT 426-15-05200.
-1шт.
|$35
-1шт.
