1
CHAMBER, REAR BRAKE (SEE PG 03-080)
-29шт.
|$1
01435-01235
BOLT, MOUNT REAR BRAKE CHAMBER
4шт.
2
7861-99-1600
SENSOR, STROKE - REAR BRAKE CHAMBER
1шт.
3
07002-02034
O-RING, SENSOR
1шт.
4
566-35-14410
ELBOW
1шт.
5
07104-20410
HOSE, BRAKE CHAMBER TO AIR BOX
1шт.
6
421-09-12170
CLIP, HOSE
4шт.
|$7
01010-51020
BOLT, CLIP
4шт.
|$8
01643-31032
WASHER
4шт.
7
07238-00422
CONNECTOR, AT AIR BOX
2шт.
8
07104-20404
HOSE, AIR BOX TO SLACK ADJUSTER
1шт.
9
426-35-15940
TUBE, AIR BOX TO SLACK ADJUSTER
1шт.
10
421-09-12170
CLIP, TUBE
3шт.
|$13
01010-51020
BOLT, CLIP
3шт.
|$14
01643-31032
WASHER
3шт.
11
07235-10422
ELBOW, AT SLACK ADJUSTER
1шт.
12
07002-02034
O-RING
1шт.
13
ADJUSTER, SLACK (SEE PG 03-084)
-29шт.
|$18
01010-51440
BOLT, MOUNT SLACK ADJUSTER
2шт.
|$19
01643-31445
WASHER
2шт.
14
426-35-15830
BRACKET, MOUNT SLACK ADJUSTER
1шт.
|$21
01010-51230
BOLT, MOUNT BRACKET
4шт.
|$22
01643-31232
WASHER
4шт.
15
07002-02034
O-RING
1шт.
16
07230-20315
UNION, AT SLACK ADJUSTER
1шт.
17
426-35-15930
TUBE, SLACK ADJUSTER TO LH WHEEL BRAKE
1шт.
18
08035-01510
CLIP, HOSE
1шт.
|$27
01010-51020
BOLT, CLIP
1шт.
|$28
01643-31032
WASHER
1шт.
19
07109-20308
HOSE, SLACK ADJUSTER TO LH WHEEL BRAKE
1шт.
20
426-35-15910
TUBE, SLACK ADJUSTER TO LH WHEEL BRAKE
1шт.
21
08035-01510
CLIP, TUBE
1шт.
|$32
01010-51025
BOLT, CLIP
1шт.
|$33
01643-31032
WASHER
1шт.
22
07233-20315
ELBOW, AT LH WHEEL BRAKE
1шт.
23
07042-30108
PLUG
1шт.
24
07239-12009
NUT
1шт.
25
07002-02034
O-RING
1шт.
26
426-35-11891
COVER, LH TUBE PROTECTOR
1шт.
|$39
01010-51020
BOLT, MOUNT COVER
2шт.
|$40
01010-51045
BOLT, MOUNT COVER
2шт.
|$41
01643-31032
WASHER
4шт.
27
6131-22-3750
SPACER
2шт.
28
07002-02034
O-RING
1шт.
29
07230-20315
UNION, AT SLACK ADJUSTER
1шт.
30
07109-20308
HOSE, SLACK ADJUSTER TO RH WHEEL BRAKE
1шт.
31
426-35-15920
TUBE, SLACK ADJUSTER TO RH WHEEL BRAKE
1шт.
32
08035-01510
CLIP, TUBE
2шт.
|$48
01010-51020
BOLT, CLIP
1шт.
|$49
01643-31032
WASHER
1шт.
33
426-35-15820
BRACKET, BRAKE LINES TO AXLE HOUSING
1шт.
|$51
01010-51230
BOLT, BRACKET
2шт.
|$52
01643-31232
WASHER
2шт.
34
07233-20315
ELBOW, AT RH WHEEL BRAKE
1шт.
35
07042-30108
PLUG
1шт.
36
07239-12009
NUT
1шт.
37
07002-02034
O-RING
1шт.
38
426-35-11991
COVER, RH TUBE PROTECTOR
1шт.
|$58
01010-51020
BOLT, MOUNT COVER
2шт.
|$59
01010-51045
BOLT, MOUNT COVER
2шт.
|$60
01643-31032
WASHER
4шт.
39
6131-22-3750
SPACER
2шт.
40
07281-00197
CLAMP, HOSE
4шт.
41
07260-20963
HOSE, BREATHER LINE
1шт.
42
04434-51610
CLIP, HOSE
1шт.
|$65
01010-51020
BOLT, CLIP
1шт.
|$66
01643-31032
WASHER
1шт.
43
426-35-15631
TEE
1шт.
44
07030-01030
BREATHER
1шт.
