1
426-06-13113
SUPPORT, LH WORK LIGHTS
1шт.
2
426-06-13123
SUPPORT, RH WORK LIGHTS
1шт.
3
01010-51230
BOLT, MOUNT WORK LIGHT SUPPORTS
8шт.
4
01643-31232
WASHER
8шт.
5
419-06-13221
BRACKET, LH
1шт.
6
419-06-13231
BRACKET, LH
1шт.
7
01010-51225
BOLT, MOUNT BRACKET
6шт.
8
01643-31232
WASHER
6шт.
9
08037-03614
GROMMET
2шт.
10
LIGHT, FRONT DRIVING (SEE PG 01-052)
-29шт.
11
419-06-13301
COVER
2шт.
12
01220-40610
SCREW, MOUNT COVER
8шт.
13
01602-20619
WASHER, LOCK
8шт.
14
LIGHT, LH TURN SIGNAL AND PARKING (SEE PG 01-050)
-29шт.
|$14
LIGHT, RH TURN SIGNAL AND PARKING (SEE PG 01-048)
-29шт.
15
01220-40516
SCREW, MOUNT PARKING LIGHTS
8шт.
16
01601-20513
WASHER, LOCK
8шт.
17
421-06-12321
HARNESS, DRIVING AND PARKING LIGHTS
2шт.
18
08036-12210
CLIP
2шт.
19
01010-51020
BOLT
2шт.
20
01643-31032
WASHER
2шт.
21
419-06-13241
COVER
2шт.
22
01220-40610
SCREW, MOUNT COVER
8шт.
23
01602-20619
WASHER, LOCK
8шт.
24
08052-02411
CLIP
2шт.
25
01220-40608
SCREW
2шт.
26
01641-20608
WASHER
2шт.
27
08037-03620
GROMMET
2шт.
28
HARNESS, FRONT LINE (SEE PG 01-054)
-29шт.
