1
FRAME, FRONT (E.C.S.S.) (SEE PG 05-002)
-29шт.
2
BRACKET (SEE PG 01-054)
-29шт.
3
01435-01225
BOLT, BRACKET MOUNT
2шт.
4
VALVE, E.C.S.S (SEE PG 01-054)
-29шт.
5
01011-51225
BOLT
2шт.
6
01643-31232
WASHER
2шт.
7
07230-20522
UNION
5шт.
8
07002-12434
O-RING
10шт.
9
04434-53411
CLIP
2шт.
10
07095-20523
CUSHION
2шт.
11
01435-01016
BOLT
2шт.
12
42A-16-11231
PLATE
2шт.
13
01435-01016
BOLT
2шт.
14
07123-00510
HOSE, HIGH ACCUMULATOR TO VALVE
1шт.
15
07235-50522
ELBOW
2шт.
16
07042-30108
PLUG
4шт.
17
01010-51230
BOLT
4шт.
18
01643-31232
WASHER
4шт.
19
426-S99-1110
BRACKET, ACCUMULATOR
2шт.
20
01010-51235
BOLT, MOUNT BRACKET ACCUMULATOR
8шт.
21
01643-31232
WASHER, MOUNT BRACKET ACCUMULATOR
8шт.
22
721-32-15021
ACCUMULATOR, HIGH PRESSURE
1шт.
23
421-S99-1351
U-BOLT, ACCUMULATOR
2шт.
24
426-43-19150
NUT, U-BOLT
4шт.
25
01643-31232
WASHER
4шт.
26
721-32-15010
ACCUMULATOR, LOW PRESSURE
1шт.
27
07123-00505
HOSE, ACCUMULATOR TO VALVE
1шт.
28
07123-00505
HOSE, LIFT CYL BOTTOM TUBE TO VALVE
1шт.
29
07236-50522
ELBOW
2шт.
30
TUBE, MAIN CONTROL TO E.C.S.S. VALVE (SEE PG 05-144)
-29шт.
31
07102-20506
HOSE, FROM ITEM 30 TO E.C.S.S. VALVE
1шт.
32
418-S99-1140
SWITCH, E.C.S.S. PRESSURE
1шт.
33
07002-01423
O-RING
1шт.
34
423-62-11710
ELBOW
1шт.
35
07123-00504
HOSE, E.C.S.S. VALVE TO LIFT CYL ROD END TUBE
1шт.
36
TUBE, LIFT CYL ROD END (SEE PG 06-062)
-29шт.
37
TUBE, TO LIFT CYLINDER BOTTOM END (SEE PG 06-062)
-29шт.
