|$0
TRANSMISSION ASSEMBLY (SEE PG 02-014)
-29шт.
1
426-15-12330
CARRIER, 3rd CLUTCH
1шт.
2
426-15-12430
GEAR
4шт.
3
426-15-12960
BEARING
4шт.
4
09233-13220
WASHER, THRUST
8шт.
|$5
426-15-00150
SHAFT ASSEMBLY
4шт.
5
NSS
SHAFT
1шт.
6
07043-00108
PLUG
1шт.
7
04025-00620
PIN, SPRING
4шт.
8
426-15-12240
GEAR
1шт.
9
04064-09530
RING, RETAINING
1шт.
10
426-15-12620
GEAR, RING
1шт.
11
426-15-11140
HOUSING, 3rd CLUTCH
1шт.
12
04020-01434
PIN, DOWEL
12шт.
13
426-15-19210
RING, SEAL - 3rd CLUTCH HOUSING
1шт.
14
426-15-12740
PISTON, 3rD CLUTCH
1шт.
15
175-15-59250
RING, SEAL - 3rd CLUTCH PISTON
1шт.
16
198-15-22810
DISC
3шт.
17
426-15-12720
PLATE
2шт.
18
175-15-42880
SPRING
18шт.
19
234-15-15230
SPRING
12шт.
20
RING, RETAINING - 1st CLUTCH (SEE PG 02-040)
-29шт.
21
PIN, 1st CLUTCH (SEE PG 02-040)
-29шт.
22
SHAFT, 1st CLUTCH (SEE PG 02-040)
-29шт.
N/I
SERVICE KIT, TRANSMISSION (SEE PG 02-060)
-29шт.
|$27
-1шт.
|$26
F1 - INCLUDED IN SERVICE KIT 426-15-05200.
-1шт.
|$28
-1шт.
