Запчасти Komatsu WA600-1LE ГОЛОВКА ЦИЛИНДРОВ ГОЛОВКА ЦИЛИНДРОВ

1

1238 656 H1

WASHER, PLAIN (3/4 INCH)

36шт.

2

1307 720 H1

BOLT (3/4 - 16x8 INCH)

36шт.

3

1307 938 H1

GASKET, CYLINDER HEAD

6шт.

|$3

1307 939 H91

HEAD, CYLINDER

1шт.

4

1307 940 H1

SEAL, VALVE STEM

4шт.

5

1307 941 H1

COLLET, VALVE

8шт.

6

1307 942 H1

VALVE, EXHAUST

2шт.

7

1307 943 H1

VALVE, INTAKE

2шт.

8

1307 944 H1

ROTATOR, VALVE

4шт.

9

1307 945 H1

SPRING, VALVE

4шт.

10

1240 019 H1

PIN, GROOVE

2шт.

11

1307 946 H1

INSERT, VALVE

2шт.

12

1307 947 H1

INSERT, VALVE

2шт.

13

1238 634 H1

PLUG, EXPANSION

1шт.

14

6720-11-1150

PLUG, EXPANSION

8шт.

15

1238 755 H1

PLUG, EXPANSION

2шт.

16

1307 948 H1

PLUG, THREADED

1шт.

|$17

NSS

PLUG, THREADED

1шт.

|$18

1307 949 H1

SEAL, O-RING

1шт.

17

1246 131 H91

PLUG, THREADED

1шт.

|$20

NSS

PLUG, THREADED

1шт.

|$21

6735-21-4160

SEAL, O-RING

1шт.

18

NSS

HEAD, CYLINDER

1шт.

19

NSS

GUIDE, VALVE STEM

4шт.

20

1307 952 H1

RETAINER, VALVE SPRING

4шт.

21

1307 953 H1

PLUG, PIPE

1шт.

|$29

-1шт.

|$27

R1 - REMANUFACTURED ASSEMBLY AVAILABLE; REFER TO REMANUFACTURED

-1шт.

|$28

ASSEMBLIES CATALOG.

-1шт.
