|$0
TRANSMISSION ASSEMBLY (SEE PG 02-014)
-29шт.
|$1
VALVE ASSEMBLY, TRANS. CONTROL (SEE PG 02-044)
-29шт.
|$2
428-15-00120
VALVE ASSEMBLY, SOLENOID
1шт.
1
424-15-17112
BODY, SOLENOID VALVE
1шт.
2
07042-20108
PLUG
2шт.
3
424-15-17212
WIRE ASSEMBLY, CONNECTOR
1шт.
4
424-15-17230
GASKET, WIRE ASSEMBLY
1шт.
5
01220-40310
SCREW, MOUNT WIRE ASSEMBLY
4шт.
6
01601-20307
WASHER, LOCK
4шт.
7
568-15-15960
BUSHING
1шт.
8
568-15-15970
PAD
1шт.
9
569-15-37310
SPOOL
6шт.
10
07000-71009
O-RING, SPOOL
6шт.
11
424-15-17340
PLATE
1шт.
12
561-15-47210
VALVE, SOLENOID
6шт.
N/I
568-15-17260
O-RING
1шт.
N/I
07000-31006
O-RING
1шт.
N/I
561-15-47230
SCREEN
1шт.
13
01220-40416
SCREW, MOUNT SOLENOID
24шт.
14
01601-20410
WASHER
24шт.
15
424-15-17160
PROTECTOR
1шт.
16
424-15-17150
STAND
1шт.
17
01220-40412
SCREW
4шт.
18
01601-20410
WASHER
4шт.
19
568-15-17220
TERMINAL
1шт.
20
01220-40310
SCREW, MOUNT TERMINAL
4шт.
21
01601-20307
WASHER, LOCK
4шт.
22
424-15-17131
COVER
1шт.
23
424-15-17141
GASKET, COVER
1шт.
24
01252-30618
BOLT, MOUNT COVER
12шт.
25
01602-20619
WASHER, LOCK
12шт.
26
424-15-17121
GASKET, SOLENOID VALVE BODY
1шт.
27
01011-31040
BOLT, MOUNT SOLENOID VALVE BODY
5шт.
28
01010-31085
BOLT, MOUNT SOLENOID VALVE BODY
4шт.
29
01643-31032
WASHER
9шт.
N/I
426-15-05301
SERVICE KIT, TRANSMISSION CONTROL VALVE
-1шт.
|$36
(SEE PG 02-060)
-29шт.
|$39
-1шт.
|$38
F1 - INCLUDED IN SERVICE KIT 426-15-05301.
-1шт.
|$40
-1шт.
