Запчасти Komatsu WA800-3LC H-A ГИДР. НАСОС. НАСОС ASSEMBLY SAR ГИДРАВЛИКА

|$0

PUMP ASSEMBLY (SEE FIG. H1610-01A0 )

SN: A50001--UP

-1шт.

|$1

705-34-30450

PUMP ASSEMBLY (SAR32)

SN: A50001--UP

1шт.

1

705-19-01541

BRACKET

SN: A50001--UP

1шт.

|$3

705-17-01351

BUSHING, PLANE

SN: A50001--UP

2шт.

2

705-18-30110

CASE, GEAR

SN: A50001--UP

1шт.

3

705-17-01221

CARRIER ASSEMBLY

SN: A50001--UP

1шт.

|$6

705-17-01351

BUSHING, PLANE

SN: A50001--UP

2шт.

4

04020-00820

PIN, DOWEL

SN: A50001--UP

4шт.

5

705-17-01381

RING

SN: A50001--UP

2шт.

6

705-19-30360

GEAR, DRIVE

SN: A50001--UP

1шт.

7

705-18-30810

GEAR, DRIVEN

SN: A50001--UP

1шт.

8

705-17-01610

PLATE, SIDE

SN: A50001--UP

2шт.

9

705-17-01440

RING, BACK-UP

SN: A50001--UP

2шт.

10

705-17-01470

SEAL, RING

SN: A50001--UP

2шт.

11

705-17-02790

BOLT

SN: A50001--UP

4шт.

12

01643-51232

WASHER

SN: A50001--UP

4шт.

13

04020-01228

PIN, DOWEL

SN: A50001--UP

2шт.

14

705-17-01851

SEAL, OIL

SN: A50001--UP

1шт.

15

705-17-01860

PLATE

SN: A50001--UP

1шт.

16

04065-03212

RING, SNAP

SN: A50001--UP

1шт.

17

705-19-01330

COUPLING

SN: A50001--UP

1шт.

18

705-17-03380

O-RING

SN: A50001--UP

1шт.

19

705-19-03470

BOLT

SN: A50001--UP

4шт.

20

705-17-04980

WASHER

SN: A50001--UP

4шт.
