Запчасти Komatsu WA800-3LC K7-8A КОНДИЦ.DITINER КОНДЕНСАТОР OPERATORS ОБСТАНОВКА И СИСТЕМА УПРАВЛЕНИЯ

|$0

425-07-21530

CONDENSER ASSEMBLY

SN: A50001--UP

2шт.

1

ND447710-0410

CORE, CONDENSER

SN: A50001--UP

1шт.

2

ND146240-2033

SHROUD, FAN

SN: A50001--UP

1шт.

3

ND047741-1320

BRACKET

SN: A50001--UP

1шт.

4

ND047750-4860

BRACKET

SN: A50001--UP

1шт.

5

ND022770-0212

FAN

SN: A50001--UP

1шт.

6

ND263500-0280

MOTOR

SN: A50001--UP

1шт.

7

ND915700-6161

BOLT WITH WASHER

SN: A50001--UP

6шт.

8

ND949056-2230

NUT

SN: A50001--UP

1шт.

9

ND949011-3040

WASHER, STEEL PLATE

SN: A50001--UP

1шт.

10

ND146680-9090

CLAMP, PIPING

SN: A50001--UP

2шт.

11

ND146810-1470

RESISTOR, BLOWER

SN: A50001--UP

1шт.

12

ND949047-1000

BOLT WITH WASHER

SN: A50001--UP

6шт.

13

ND146982-0030

NUT

SN: A50001--UP

6шт.

14

ND146421-9870

WIRE

SN: A50001--UP

1шт.

15

ND146713-0660

PLATE, CAUTION

SN: A50001--UP

1шт.
