Запчасти Komatsu WA900-1LC A20008-UP ГЕНЕРАТОР 7 AMP - V DELCO-REMY ЭЛЕКТРИКА

|$0

1296 910 H91

ALTERNATOR ASSEMBLY, 75 AMP

1шт.

1

1285 725 H1

PLATE, COVER

1шт.

2

1268 363 H1

BOLT, MOUNTING

4шт.

3

1213 274 H1

CAP, TERMINAL

1шт.

|$4

1285 726 H1

HOUSING ASSEMBLY, RECTIFIER

1шт.

4

470 233 C1

BEARING

1шт.

5

1213 242 H1

BUSHING, MOUNTING

1шт.

6

NSS

HOUSING, RECTIFIER

1шт.

7

470 232 C1

BEARING

1шт.

8

585 631 C1

RECTIFIER BRIDGE

1шт.

9

1268 366 H1

BOLT, MOUNTING

2шт.

10

1268 369 H1

WASHER, FLAT

2шт.

11

1285 727 H1

DIODE TRIO

1шт.

12

1213 256 H1

PACKAGE, TERMINAL

1шт.

13

1285 728 H1

CONNECTOR

1шт.

14

1285 729 H1

CONNECTOR

1шт.

15

1268 364 H1

BOLT, MOUNTING

1шт.

16

1310 184 H1

NUT, HEX

4шт.

17

1285 730 H1

PACKAGE, OUTPUT TERMINAL

1шт.

18

1218 115 H1

REGULATOR

1шт.

19

1268 367 H1

BOLT, MOUNTING - INSULATED

2шт.

20

1268 365 H1

BOLT, MOUNTING - GROUND

1шт.

21

1432 779 H1

CAPACITOR

1шт.

|$23

1296 911 H1

STATOR ASSEMBLY

1шт.

22

NSS

STATOR

1шт.

23

NSS

GROMMET, WIRE

1шт.

24

NSS

LEAD TERMINAL

3шт.

25

1285 735 H1

FIELD COIL AND SUPPORT

1шт.

26

1213 252 H1

BOLT, MOUNTING

4шт.

27

1213 260 H1

BOLT, GROUND TERMINAL

1шт.

28

120 380

WASHER, LOCK - 1/4

1шт.

29

1213 254 H1

ROTOR

1шт.

30

1285 736 H1

RETAINER, BEARING

1шт.

31

1285 737 H1

COLLAR, BEARING

1шт.

32

1213 268 H1

BEARING

1шт.

33

1213 262 H1

FRAME, DRIVE END

1шт.

34

1285 739 H1

BOLT, MOUNTING

4шт.

35

1213 271 H1

BOLT, MOUNTING

4шт.

36

1213 273 H1

NUT, PULLEY

1шт.

37

1268 370 H1

WASHER, FLAT

1шт.

38

1285 738 H1

FAN, COOLING

1шт.

|$44

-1шт.

|$42

R1 - REMANUFACTURED ASSEMBLY AVAILABLE; REFER TO REMANUFACTURED

-1шт.

|$43

ASSEMBLIES CATALOG.

-1шт.
