1
DAMPER ASSEMBLY (SEE FIG. K0710-03A0 )
SN: A50001--UP
-1шт.
2
DUCT ASSEMBLY, AIR (SEE FIG. K0711-04A0 )
SN: A50001--UP
-1шт.
3
425-07-21160
RELAY
SN: A50001--UP
8шт.
4
421-07-21190
CAP
SN: A50001--UP
2шт.
5
421-07-21280
HOSE
SN: A50001--UP
2шт.
6
20Y-979-3120
TANK, RECEIVER
SN: A50001--UP
1шт.
7
01435-00620
BOLT
SN: A50001--UP
2шт.
8
AIR CONDITIONER UNIT (SEE FIG. K0710-05A0 )
SN: A50001--UP
-1шт.
9
425-07-21121
CONTROLLER
SN: A50001--UP
1шт.
10
COMPRESSOR (SEE FIG. K0710-07A0 )
SN: A50001--UP
-1шт.
11
CONDENSER ASSEMBLY (SEE FIG. K0710-08A0 )
SN: A50001--UP
-1шт.
12
FILTER BOX ASSEMBLY (SEE FIG. K0710-02A0 )
SN: A50001--UP
-1шт.
13
GRILLE (SEE FIG. K0712-01A0 )
SN: A50001--UP
-1шт.
14
WIRING HARNESS (SEE FIG. K0711-04A0 )
SN: A50001--UP
-1шт.
