1
01435-01016
BOLT
SN: A50001--UP
6шт.
2
427-54-21921
BAFFLE, LOWER
SN: A50001--UP
1шт.
3
427-54-21931
BAFFLE, UPPER
SN: A50001--UP
1шт.
4
427-54-21941
BAFFLE, RIGHT
SN: A50001--UP
1шт.
5
427-54-21951
BAFFLE, LEFT
SN: A50001--UP
1шт.
6
427-54-22160
BAFFLE, UPPER
SN: A50001--UP
1шт.
7
427-54-A1210
BAFFLE, LEFT
SN: A50001--UP
1шт.
8
427-54-A1220
BAFFLE, RIGHT
SN: A50001--UP
1шт.
9
427-03-25100
OIL COOLER ASSEMBLY, HYDRAULIC
SN: A50001--UP
1шт.
10
PLATE (SEE FIG. C0110-02A0 )
SN: A50001--UP
-1шт.
11
BOLT (SEE FIG. C0110-02A0 )
SN: A50001--UP
-1шт.
12
WASHER (SEE FIG. C0110-02A0 )
SN: A50001--UP
-1шт.
13
BOLT (SEE FIG. C0110-02A0 )
SN: A50001--UP
-1шт.
14
WASHER (SEE FIG. C0110-02A0 )
SN: A50001--UP
-1шт.
15
SPACER (SEE FIG. C0110-02A0 )
SN: A50001--UP
-1шт.
