1
45A-9FB-2212YD
PIPE,(FOR S/L/P/J-TYPE)
SN: 1196-UP
1шт.
|$33
0
PIPE,(FOR S/L/P/J-TYPE)
SN: 1001-1195
1шт.
|$34
45A-9FB-2212WD
PIPE,(FOR S/L-TYPE) (COLD)
SN: 1196-UP
1шт.
|$35
0
PIPE,(FOR S/L-TYPE) (COLD)
SN: 1001-1195
1шт.
2
01010-80820
BOLT
SN: 1001-UP
2шт.
3
01602-20825
WASHER,SPRING
SN: 1001-UP
2шт.
4
01643-30823
WASHER
SN: 1001-UP
2шт.
5
07627-00203
HOSE
SN: 1196-UP
2шт.
|$40
07627-00203
HOSE
SN: 1001-1195
1шт.
6
45C-2HF-8590
HOSE
SN: 1001-1195
1шт.
7
45B-1FS-1730
ELBOW
SN: 1001-UP
1шт.
8
07235-10210
ELBOW
SN: 1001-UP
1шт.
9
07002-11423
O-RING
SN: 1001-UP
2шт.
10
3LA-71-15112YD
SUPPORT,(FOR S/L/P/J-TYPE) (2-ROLLER)
SN: 1001-UP
1шт.
|$46
3LA-71-15112WD
SUPPORT,(FOR S/L-TYPE)(2-ROLLER)(COLD)
SN: 1001-UP
1шт.
|$47
3LA-71-15312YD
SUPPORT,(FOR S/L/P/J-TYPE) (3-ROLLER)
SN: 1001-UP
1шт.
|$48
3LA-71-15312WD
SUPPORT,(FOR S/L-TYPE)(3-ROLLER)(COLD)
SN: 1001-UP
1шт.
11
3LA-71-15651
PLATE
SN: 1001-UP
2шт.
12
01010-81025
BOLT
SN: 1001-UP
4шт.
13
01643-31032
WASHER
SN: 1001-UP
4шт.
14
01010-81635
BOLT
SN: 1001-UP
4шт.
15
01643-31645
WASHER
SN: 1001-UP
4шт.
16
3LA-71-15610
SHAFT
SN: 1001-UP
2шт.
17
01016-50830
BOLT
SN: 1001-UP
4шт.
18
01580-10806
NUT
SN: 1001-UP
4шт.
19
3LA-71-15811YD
PIPE ASS'Y,(FOR S/L/P/J-TYPE)
SN: 1001-UP
1шт.
|$58
3LA-71-15811WD
PIPE,(FOR S/L-TYPE) (COLD)
SN: 1001-UP
1шт.
20
3LA-71-15821YD
PIPE,(FOR S/L/P/J-TYPE)
SN: 1001-UP
1шт.
|$60
3LA-71-15821WD
PIPE,(FOR S/L-TYPE) (COLD)
SN: 1001-UP
1шт.
21
01010-80816
BOLT
SN: 1001-UP
1шт.
22
01010-80820
BOLT
SN: 1001-UP
2шт.
23
01602-20825
WASHER,SPRING
SN: 1001-UP
3шт.
24
01643-30823
WASHER
SN: 1001-UP
3шт.
