1
17C640
BOLT 5
2
6717560
PIN 1.25'' x 6.46'' (31,8 mm x 164,0 mm)
3
85D6
NUT, 5
4
10H35
FITTING, GREASE 10
5
7216445
BUSHING, WELD-ON W/Ref. 38 - Was 6732265
6
6737134
LIFT ARM 38 mm (1.5'') dia Bob-Tach pins
7
6700743
SPRING Was 6579072 - B
8
6519178
BUMPER rubber
9
61D6
NUT 5
10
6700533
SPACER
11
17C656
BOLT
12
6737274
LIFT ARM STOP
13
6714810
PIN retainer
14
31C1264
BOLT for Ref. 18 (6707180 pin)
14
47C1064
BOLT for Ref. 18 (7101078 pin)
15
6718723
WASHER
16
6651709
SEAL
17
6700463
CUP, SEAL seal
18
6707180
PIN, PIVOT W/.75'' threaded hole - 3.90'' (99,1 mm) long - 2.70'' (68,6 mm) taper - Use W/Ref. 14 (31C1264 bolt)
18
7101078
PIN, PIVOT TAPERED W/.625'' threaded hole - 4.05'' (102,9 mm) long - 2.34'' (59,4 mm) taper - Use W/Ref. 14 (47C1064 bolt)
19
10H25
FITTING, GREASE 5
20
6703363
BUSHING weld on - Also Order Ref. 22
21
6737623
BUSHING weld on - Also Order Ref. 22
22
6704288
PIN, PIVOT 32 x 178 mm (1.25 x 7'')
23
CYLINDER See Illustration TILT CYLINDER/ TS1098 TILT
24
225855
SEAL, OIL 10 38 mm (1.5'') OD
25
BOB-TACH See Illustration BOB-TACH/ PE2074
26
743332
FITTING, GREASE 5
27
6716601
PIN, PIVOT
28
17C620
BOLT
29
6718789
PIN
30
11H15
GREASE FITTING
31
CYLINDER See Illustration LIFT CYLINDER/ PE3175 LIFT
32
6717025
BUSHING weld-on - Was 6703616 - B
33
6555987
BUSHING weld on
34
ARM NLA - R.H. - weld on
34
ARM NLA - L.H. - weld on
35
12H15
FITTING, GREASE 5
36
6704436
PAD foam - self adhesive
37
17C660
BOLT
38
6717562
BUSHING, WEAR
39
6705091
TAB weld on
40
6727545
PLATE weld on
41
6727544
PLATE weld on
42
7160421
BUSHING, TAPERED weld on - service only - Use W/Ref. 18 (7101078 pin) - Was 7120498 - B,D
