Запчасти Doosan Daewoo F.O.P.S. GUARD OPTION PARTS

-

2623-1286

F.O.P.S GUARD ASS'Y

SC: D

-2шт.

1

2197-1747B

SUPPORT;MOUNT(LH)

desc: SUPPORT

1шт.

2

2197-1748B

SUPPORT;MOUNT(RH)

desc: SUPPORT

1шт.

3

2623-1253B

F.O.P.S GUARD

desc: GARDE

1шт.

4

S0521451

BOLT

desc: BOULON A 6 PANS

6шт.

5

S5102901

WASHER;SPRING

desc: RONDELLE ELASTIQUE

14шт.

6

S0521661

BOLT M16X2.0X50

desc: BOULON A 6 PANS

8шт.

7

S0558853

BOLT M10X1.5X65

desc: BOULON A 6 PANS

6шт.

8

S5102603

WASHER;SPRING

desc: RONDELLE ELASTIQUE

6шт.

9

2462-1005

COVER

desc: COUVERCLE

1шт.

10

2142-1123

GUARD;FRONT

desc: GARDE

1шт.

11

S0558153

BOLT M10X1.5X30

desc: BOULON A 6 PANS

5шт.

12

2122-1002D1

RIVET

desc: RIVET

4шт.

13

2190-3502B

PLATE;NAME

desc: PLAQUE D'IDENTIFICATION

1шт.

14

190-00003

PLATE;NAME(F.O.G.S)

desc: PLAQUE D'IDENTIFICATION

1шт.

15

2114-1058D39

WASHER

desc: RONDELLE M16

14шт.

16

2114-1058D10

WASHER

desc: RONDELLE PLATE

5шт.

17

603-00182

FRAME;BED(FOR FOG)

desc: BATI PRINCIPAL

1шт.
